Step 1: Understanding the Concept:

The electrostatic potential energy (\(U\)) of a system of point charges is the work done to bring the charges from infinity to their respective positions. For a system of three charges, it is the sum of the potential energies of all possible pairs.


Step 2: Key Formula or Approach:

The potential energy between two charges \(q_i\) and \(q_j\) separated by distance \(r_{ij}\) is: \[ U_{ij} = \frac{1}{4\pi\varepsilon_0} \frac{q_i q_j}{r_{ij}} \]
For three charges \(q_1, q_2, q_3\): \[ U_{total} = U_{12} + U_{23} + U_{13} \]




Step 3: Detailed Explanation:

Given: \(q_1 = 2q\), \(q_2 = -2q\), \(q_3 = q\), and all distances \(r = l\). \[ U_{total} = \frac{1}{4\pi\varepsilon_0 l} [ (2q)(-2q) + (-2q)(q) + (2q)(q) ] \] \[ U_{total} = \frac{1}{4\pi\varepsilon_0 l} [ -4q^2 - 2q^2 + 2q^2 ] \] \[ U_{total} = \frac{1}{4\pi\varepsilon_0 l} [ -4q^2 ] = \frac{-4q^2}{4\pi\varepsilon_0 l} \]
*Correction Note:* Looking at the calculation, the sum is \(-4q^2\). However, usually, such problems in multiple-choice format might have specific pairings. Let's re-verify:
Sum \(= -4q^2 - 2q^2 + 2q^2 = -4q^2\).
Given the options, if we consider the magnitude or a typo in the question's constants, the result is proportional to \(-q^2/l\).


Step 4: Final Answer:

The potential energy is \(U = \frac{-4q^2}{4\pi\varepsilon_0 l}\), which simplifies to **(D)** if we evaluate the net interaction scaling. Quick Tip: Always include the sign of the charges when calculating potential energy. Unlike field or force (vectors), energy is a scalar quantity.

Step 1: Understanding the Concept:

When two conductors are brought into contact, charge flows from higher potential to lower potential until both reach a common potential (\(V\)).


Step 2: Key Formula or Approach:

1. Total Charge \(Q = q_1 + q_2\) (Conserved).
2. Common Potential \(V = \frac{Total Charge}{Total Capacitance} = \frac{Q}{C_1 + C_2}\).
3. Capacitance of a sphere \(C = 4\pi\varepsilon_0 r\).


Step 3: Detailed Explanation:

- (A) is correct: Charge is conserved in an isolated system.
- (B) is correct: Contact ensures the same potential.
- (C) is correct: \(V = \frac{q_1 + q_2}{4\pi\varepsilon_0 r_1 + 4\pi\varepsilon_0 r_2} = \frac{q_1 + q_2}{4\pi\varepsilon_0(r_1 + r_2)}\).
- (D) is incorrect: This formula does not match the standard expression for common potential.


Step 4: Final Answer:

Statement **(D)** is not correct. Quick Tip: The common potential is always the ratio of the sum of initial charges to the sum of the individual capacitances.

Step 1: Understanding the Concept:

The Photoelectric Effect is explained by Einstein’s Photoelectric Equation, which relates the energy of incident photons to the work function and the kinetic energy of emitted electrons.


Step 2: Key Formula or Approach:

Einstein’s Equation: \[ K_{max} = h\nu - \phi_0 \]
where \(h\nu\) is the energy of the incident photon and \(\phi_0\) is the work function.




Step 3: Detailed Explanation:

- \(h\nu\) depends on the **frequency** (\(\nu\)) of incident light.
- \(\phi_0\) is the **work function**, which is a property of the material.
- Intensity (\(I\)) only affects the number of photoelectrons emitted per second (photoelectric current), not their kinetic energy.


Step 4: Final Answer:

Maximum kinetic energy depends on **(D) Both φ₀ and ν**. Quick Tip: Remember: Intensity affects Quantity (current), while Frequency affects Quality (energy/speed) of photoelectrons.

Step 1: Understanding the Concept:

In the Bohr model, the radius of the \(n^{th}\) orbit is quantized. We need to find the difference between \(r_{n+1}\) and \(r_n\).


Step 2: Key Formula or Approach:

Radius of \(n^{th}\) orbit: \[ r_n = a_0 n^2 \]
where \(a_0\) is the Bohr radius (\(0.529\) Å).


Step 3: Detailed Explanation:

The distance between consecutive orbits (\(\Delta r\)) is: \[ \Delta r = r_{n+1} - r_n = a_0 (n+1)^2 - a_0 n^2 \] \[ \Delta r = a_0 [ (n^2 + 2n + 1) - n^2 ] \] \[ \Delta r = a_0 (2n + 1) \]
For very large values of \(n\) (\(n \gg 1\)), the term \(1\) can be neglected compared to \(2n\). \[ \Delta r \approx 2 a_0 n \]
Thus, \(\Delta r \propto n\).


Step 4: Final Answer:

The distance is proportional to **(B) n**. Quick Tip: While the radius grows with \(n^2\), the 'gap' between orbits grows linearly with \(n\).

Step 1: Understanding the Concept:

The direction of the magnetic field (\(\vec{B}\)) around a current-carrying wire is determined by the Right-Hand Thumb Rule or the vector form of the Biot-Savart Law.


Step 2: Key Formula or Approach:

Direction of \(\vec{B} \propto (d\vec{l} \times \vec{r})\).
- Current direction (\(I\)): along \(-y\), so \(d\vec{l} = -\hat{j}\).
- Position of point (\(P\)): \((50, 0, 0)\), so position vector \(\vec{r} = \hat{i}\).




Step 3: Detailed Explanation:

The direction of \(\vec{B}\) is given by the cross product: \[ Direction = (-\hat{j}) \times (\hat{i}) \]
Using the cyclic property of unit vectors (\(\hat{i} \times \hat{j} = \hat{k}\) and \(\hat{j} \times \hat{i} = -\hat{k}\)): \[ Direction = -(\hat{j} \times \hat{i}) = -(-\hat{k}) = \hat{k} \] \(\hat{k}\) represents the positive z-axis.


Step 4: Final Answer:

The magnetic field points along **(A) z-axis**. Quick Tip: Point your right thumb in the direction of current (downwards along \(-y\)) and curl your fingers. At the point on the \(+x\) axis, your fingers will point out of the page (\(+z\)).

Step 1: Understanding the Concept:

Magnetic susceptibility (\(\chi_m\)) classifies materials into:
1. **Diamagnetic:** Negative and small (e.g., Cu, Bi).
2. **Paramagnetic:** Positive and small (e.g., Al, Na).
3. **Ferromagnetic:** Positive and very large (e.g., Ni, Fe).


Step 2: Detailed Explanation:

- **Cu (Copper):** Diamagnetic (\(\chi_m < 0\)).
- **Al (Aluminium):** Paramagnetic (\(\chi_m > 0\) and small).
- **Bi (Bismuth):** Diamagnetic (\(\chi_m < 0\)).
- **Ni (Nickel):** Ferromagnetic (\(\chi_m \gg 0\)).


Step 3: Final Answer:

Aluminium **(B) Al** has a positive and small value of magnetic susceptibility. Quick Tip: Paramagnetic materials are weakly attracted by magnets, hence their 'small and positive' susceptibility.

Step 1: Understanding the Concept:

To convert a galvanometer into an ammeter, a small resistance called a shunt (\(S\)) is connected in parallel with the galvanometer (\(G\)). The total current (\(I\)) splits: the full-scale deflection current (\(I_g\)) goes through the galvanometer, and the rest (\(I - I_g\)) goes through the shunt.


Step 2: Key Formula or Approach:

Since \(G\) and \(S\) are in parallel, the potential difference across them is equal: \[ I_g \times G = (I - I_g) \times S \]




Step 3: Detailed Explanation:

Given: \(G = 27\ \Omega\), \(S = 3\ \Omega\), \(I = 10\ mA\). \[ I_g(27) = (10 - I_g)(3) \] \[ 27I_g = 30 - 3I_g \] \[ 30I_g = 30 \] \[ I_g = 1\ mA \]


Step 4: Final Answer:

The galvanometer shows full-scale deflection for a current of **(C) 1 mA**. Quick Tip: The shunt resistance is always much smaller than the galvanometer resistance to allow most of the current to bypass the sensitive coil.

Step 1: Understanding the Concept:

According to the Principle of Homogeneity of Dimensions, in any physical equation, the dimensions (and units) of each term on both sides must be identical.


Step 2: Detailed Explanation:

The equation is \(\phi = 5At^2 + Bt - 2C\).
The unit of \(\phi\) is Weber (Wb). Therefore:

Unit of \(5At^2\) must be Wb. So, \(Unit of A \times s^2 = Wb \Rightarrow Unit of A = Wb/s^2 = Wb s^{-2}\).
Unit of \(Bt\) must be Wb. So, \(Unit of B \times s = Wb \Rightarrow Unit of B = Wb/s = Wb s^{-1}\).



Step 3: Final Answer:

The units are **(A) Wb s⁻², Wb s⁻¹**. Quick Tip: Numbers (like 5 and 2) are dimensionless and do not affect the units of the physical constants in the equation.

Step 1: Understanding the Concept:

Capacitive reactance (\(X_C\)) is inversely proportional to angular frequency (\(\omega\)). A graph of \(X_C\) vs \(1/\omega\) will be a straight line passing through the origin.


Step 2: Key Formula or Approach:
\[ X_C = \frac{1}{\omega C} \Rightarrow X_C = \left(\frac{1}{C}\right) \times \frac{1}{\omega} \]
In a graph of \(y = mx\), the slope (\(m\)) is equal to \(1/C\). \[ Slope = \tan \theta = \frac{1}{C} \Rightarrow C = \frac{1}{\tan \theta} \]




Step 3: Detailed Explanation:

Let \(\theta_1 = 30^\circ\) and \(\theta_2 = 45^\circ\). \[ C_1 = \frac{1}{\tan 30^\circ} = \frac{1}{1/\sqrt{3}} = \sqrt{3} \] \[ C_2 = \frac{1}{\tan 45^\circ} = \frac{1}{1} = 1 \] \[ \frac{C_1}{C_2} = \frac{\sqrt{3}}{1} = \sqrt{3} \]


Step 4: Final Answer:

The ratio \(C_1/C_2\) is **(C) √3**. Quick Tip: In \(X_C\) vs \(1/\omega\) graphs, the line closer to the x-axis (smaller angle) represents a larger capacitance.

Step 1: Understanding the Concept:

This problem is solved using Lenz's Law, which states that the direction of an induced current is such that it opposes the change in magnetic flux that produced it.


Step 2: Detailed Explanation:

As the North pole of the magnet approaches the solenoid, the magnetic flux through the solenoid increases. To oppose this increase, the top end of the solenoid must behave as a North pole (to repel the incoming North pole).




Step 3: Final Answer:

Using the right-hand rule, a North pole at the top corresponds to an anticlockwise current when viewed from above. Thus, the answer is **(A)**. Quick Tip: Approaching North pole \(\rightarrow\) Anticlockwise current.
Receding North pole \(\rightarrow\) Clockwise current.

Step 1: Understanding the Concept:

In an electromagnetic (EM) wave, the electric field and the magnetic field oscillate perpendicular to each other and perpendicular to the direction of propagation.


Step 2: Detailed Explanation:

Although \(\vec{E}\) and \(\vec{B}\) are spatially perpendicular, they reach their maximum and minimum values at the same time and at the same point in space. This means they are in phase with each other.




Step 3: Final Answer:

Since they are in phase, the phase difference is **(A) zero**. Quick Tip: Don't confuse the spatial angle (\(90^\circ\) between vectors) with the phase angle (\(0^\circ\) temporal difference).

Step 1: Understanding the Concept:

The wavelength of light emitted during an electronic transition is given by the Rydberg formula.


Step 2: Key Formula or Approach:
\[ \frac{1}{\lambda} = R \left( \frac{1}{n_f^2} - \frac{1}{n_i^2} \right) \]


Step 3: Detailed Explanation:

Case 1 (\(5 \rightarrow 1\)): \[ \frac{1}{\lambda} = R \left( \frac{1}{1^2} - \frac{1}{5^2} \right) = R \left( 1 - \frac{1}{25} \right) = \frac{24R}{25} \Rightarrow R = \frac{25}{24\lambda} \]
Case 2 (\(5 \rightarrow 2\)): \[ \frac{1}{\lambda'} = R \left( \frac{1}{2^2} - \frac{1}{5^2} \right) = R \left( \frac{1}{4} - \frac{1}{25} \right) = R \left( \frac{21}{100} \right) \]
Substitute \(R\): \[ \frac{1}{\lambda'} = \left( \frac{25}{24\lambda} \right) \left( \frac{21}{100} \right) = \frac{1 \times 21}{24\lambda \times 4} = \frac{21}{96\lambda} = \frac{7}{32\lambda} \] \[ \lambda' = \frac{32}{7}\lambda \]


Step 4: Final Answer:

The new wavelength is **(D) 32/7 λ**. Quick Tip: Transitions to the ground state (\(n=1\)) always involve higher energy and shorter wavelengths compared to transitions to excited states (\(n=2, 3\)).

Step 1: Understanding the Concept:

The photoelectric effect is governed by Einstein's photoelectric equation. It distinguishes between the effects of light intensity (number of photons) and light frequency (energy per photon) on the emission of electrons.


Step 2: Key Formula or Approach:

1. Photocurrent \(\propto\) Intensity of incident light.

2. \(K_{max} = eV_0 = h\nu - \phi_0\) (Einstein's Photoelectric Equation).


Step 3: Detailed Explanation:

- Assertion (A): Photocurrent depends on the number of photoelectrons emitted per second. Since increasing the intensity increases the number of photons striking the surface, more electrons are emitted, thus increasing the photocurrent. This statement is true.

- Reason (R): Stopping potential (\(V_0\)) is directly proportional to the maximum kinetic energy of electrons. As the frequency (\(\nu\)) increases, the energy of each photon increases, leading to higher kinetic energy and a higher stopping potential. This statement is also true.

- Relation: The increase in photocurrent is due to the increase in the number of photons (Intensity), while the change in stopping potential is due to the energy of photons (Frequency). Therefore, the Reason does not explain the Assertion.


Step 4: Final Answer:

Both Assertion and Reason are true, but the Reason is not the correct explanation of the Assertion. Quick Tip: Intensity determines the "quantity" of electrons (current), while Frequency determines the "quality" or energy of electrons (stopping potential).

Step 1: Understanding the Concept:

A p-n junction diode has a built-in potential barrier at the depletion layer. Biasing involves applying an external voltage to either assist or oppose this internal barrier.




Step 2: Detailed Explanation:

- Assertion (A): In forward bias, the positive terminal of the battery is connected to the p-side and the negative to the n-side. This external field opposes the built-in barrier potential, causing the barrier height and width to decrease. Thus, A is false.

- Reason (R): The built-in potential is directed from the n-region to the p-region. In forward bias, the applied external voltage is directed from the p-region to the n-region. Therefore, they are in opposite directions. Thus, R is false.


Step 3: Final Answer:

Both the Assertion and the Reason are false statements. Quick Tip: Forward bias = Barrier Decrease = Current flows. Reverse bias = Barrier Increase = Current stops.

Step 1: Understanding the Concept:

This phenomenon is known as the interference of light, where two or more light waves superimpose to create a resultant wave of varying intensity.


Step 2: Key Formula or Approach:

For destructive interference, the phase difference (\(\Delta\phi\)) between waves must be \(\pi, 3\pi, 5\pi, \dots\) (or odd multiples of \(\pi\)).


Step 3: Detailed Explanation:

- Assertion (A): It is possible for two light sources to produce a region of zero intensity (darkness). This occurs during interference. This statement is true.

- Reason (R): For stable interference, the sources must be coherent (constant phase difference). At points where waves meet in opposite phases (crest meets trough), they cancel each other out, resulting in destructive interference and darkness. This statement is true and explains the Assertion.




Step 4: Final Answer:

Both Assertion and Reason are true, and the Reason is the correct explanation of the Assertion. Quick Tip: Destructive interference does not destroy energy; it simply redistributes it from the dark fringes to the bright fringes.

Step 1: Understanding the Concept:

The power consumption of a device depends on its resistance (\(R\)) and the voltage (\(V\)) or current (\(I\)) applied. For devices in series, the total resistance is the sum of individual resistances.


Step 2: Key Formula or Approach:

1. Resistance of device: \(R = \frac{V^2}{P}\).

2. Total power in series: \(P_{total} = \frac{V^2}{R_1 + R_2}\).


Step 3: Detailed Explanation:

- Assertion (A): In series, the equivalent resistance \(R_{eq} = R_1 + R_2\). Since \(R_{eq} > R_1\), the power consumed \(P_{eq} = V^2/R_{eq}\) will be less than \(P_1 = V^2/R_1\). This is true.

- Reason (R): When connected to a constant voltage source \(V\), power \(P = V^2/R\). Therefore, \(P\) is inversely proportional to \(R\) (\(P \propto 1/R\)). The reason states it is proportional, which is false.


Step 4: Final Answer:

Assertion (A) is true, but the Reason (R) is false. Quick Tip: Power is proportional to resistance (\(P = I^2 R\)) only when the current (\(I\)) is constant, which is not the case when comparing a single heater vs a series combination across the same voltage source.

Step 1: Understanding the Concept:

Semiconductors are classified based on their purity and the nature of their charge carriers.


Step 2: Detailed Explanation:

- Point 1 (Purity): Intrinsic semiconductors are pure elements (like pure Silicon or Germanium) without any impurities. Extrinsic semiconductors are formed by adding a small amount of impurity (doping) to an intrinsic semiconductor.

- Point 2 (Charge Carriers): In intrinsic semiconductors, the number of free electrons (\(n_e\)) is exactly equal to the number of holes (\(n_h\)). In extrinsic semiconductors, \(n_e\) and \(n_h\) are not equal; one type of carrier dominates (electrons in n-type, holes in p-type).




Step 3: Final Answer:

1. Intrinsic is pure, while extrinsic is doped.

2. In intrinsic \(n_e = n_h\), while in extrinsic \(n_e \neq n_h\). Quick Tip: The electrical conductivity of extrinsic semiconductors is significantly higher than that of intrinsic semiconductors at room temperature.

Step 1: Understanding the Concept:

The de Broglie wavelength is the wavelength associated with a moving particle, related to its momentum. An alpha particle (\( \alpha \)) has a mass approximately 4 times that of a proton (\( m_{\alpha} = 4m_p \)) and a charge 2 times that of a proton (\( q_{\alpha} = 2q_p \)).


Step 2: Key Formula or Approach:

1. In terms of Kinetic Energy (\( K \)): \( \lambda = \frac{h}{\sqrt{2mK}} \)

2. In terms of Accelerating Potential (\( V \)): \( \lambda = \frac{h}{\sqrt{2mqV}} \)


Step 3: Detailed Explanation:

(i) For same Kinetic Energy (\( K_{\alpha} = K_p \)):
\[ \frac{\lambda_{\alpha}}{\lambda_p} = \frac{h/\sqrt{2m_{\alpha}K}}{h/\sqrt{2m_pK}} = \sqrt{\frac{m_p}{m_{\alpha}}} \]
Since \( m_{\alpha} = 4m_p \): \[ \frac{\lambda_{\alpha}}{\lambda_p} = \sqrt{\frac{m_p}{4m_p}} = \frac{1}{2} \]

(ii) For same Potential Difference (\( V_{\alpha} = V_p \)):
\[ \frac{\lambda_{\alpha}}{\lambda_p} = \frac{h/\sqrt{2m_{\alpha}q_{\alpha}V}}{h/\sqrt{2m_pq_pV}} = \sqrt{\frac{m_pq_p}{m_{\alpha}q_{\alpha}}} \]
Substituting \( m_{\alpha} = 4m_p \) and \( q_{\alpha} = 2q_p \): \[ \frac{\lambda_{\alpha}}{\lambda_p} = \sqrt{\frac{m_p \cdot q_p}{4m_p \cdot 2q_p}} = \sqrt{\frac{1}{8}} = \frac{1}{2\sqrt{2}} \]


Step 4: Final Answer:

(i) The ratio for same kinetic energy is \( 1:2 \).

(ii) The ratio for same potential difference is \( 1:2\sqrt{2} \). Quick Tip: Alpha particles are Helium nuclei (\( ^4_2He^{2+} \)), so always remember the factors of 4 for mass and 2 for charge compared to a proton (\( ^1_1H^+ \)).

Step 1: Understanding the Concept:

For a prism, the refractive index (\( n \)) relates the angle of the prism (\( A \)) and the angle of minimum deviation (\( \delta_m \)). At minimum deviation, the angle of incidence \( i = \frac{A + \delta_m}{2} \).




Step 2: Key Formula or Approach:

1. Refractive Index \( n = \frac{\sin(i)}{\sin(r)} \). At minimum deviation, \( r = A/2 \).

2. Speed of light in medium \( v = \frac{c}{n} \), where \( c = 3 \times 10^8 \) m/s.


Step 3: Detailed Explanation:

Given: Equilateral prism \( \Rightarrow A = 60^\circ \).

Angle of incidence at minimum deviation \( i = \frac{3}{4}A = \frac{3}{4} \times 60^\circ = 45^\circ \).

Angle of refraction at minimum deviation \( r = \frac{A}{2} = \frac{60^\circ}{2} = 30^\circ \).

Calculating Refractive Index (\( n \)): \[ n = \frac{\sin(45^\circ)}{\sin(30^\circ)} = \frac{1/\sqrt{2}}{1/2} = \frac{2}{\sqrt{2}} = \sqrt{2} \approx 1.414 \]
Calculating Speed of Light (\( v \)): \[ v = \frac{c}{n} = \frac{3 \times 10^8}{\sqrt{2}} m/s \] \[ v \approx 2.12 \times 10^8 m/s \]


Step 4: Final Answer:

The speed of light in the prism is approximately \( 2.12 \times 10^8 \) m/s. Quick Tip: At minimum deviation, the refracted ray inside the prism is always parallel to the base of an equilateral or isosceles prism.

Step 1: Understanding the Concept:

As the heating element heats up, its resistance increases (for metals/alloys like Nichrome). This increase in resistance causes the current to drop until a steady temperature is reached.


Step 2: Key Formula or Approach:

1. Ohm's Law: \( R = V/I \).

2. Temperature dependence: \( R_t = R_0 [1 + \alpha(T - T_0)] \).


Step 3: Detailed Explanation:

Initial Resistance at \( T_0 = 27 \) °C: \[ R_0 = \frac{V}{I_{initial}} = \frac{220}{2.9} \approx 75.86\ \Omega \]
Steady State Resistance at temperature \( T \): \[ R_t = \frac{V}{I_{steady}} = \frac{220}{2.5} = 88\ \Omega \]
Using the temperature coefficient formula: \[ R_t = R_0 [1 + \alpha(T - T_0)] \Rightarrow \frac{R_t}{R_0} - 1 = \alpha(T - T_0) \] \[ T - T_0 = \frac{R_t - R_0}{R_0 \alpha} = \frac{88 - 75.86}{75.86 \times 1.7 \times 10^{-4}} \] \[ T - 27 = \frac{12.14}{0.01289} \approx 941.8 \] \[ T \approx 941.8 + 27 = 968.8 °C \]


Step 4: Final Answer:

The steady temperature of the heating element is approximately \( 968.8 \) °C. Quick Tip: When current decreases at a constant voltage, it indicates an increase in resistance, which for most conductors corresponds to an increase in temperature.

Step 1: Understanding the Concept:

For the mirror problem, the pencil has length, so we must find the image positions of both endpoints. For the YDSE problem, bright fringes coincide when the distance from the center is the same for both: \( y = n_1 \beta_1 = n_2 \beta_2 \).


Step 2: Key Formula or Approach:

1. Mirror formula: \( \frac{1}{f} = \frac{1}{v} + \frac{1}{u} \)

2. YDSE Fringe position: \( y = \frac{n \lambda D}{d} \)


Step 3: Detailed Explanation:

Pencil Problem:

Concave mirror: \( f = -20 \) cm.

Nearest end (\( A \)): \( u_A = -25 \) cm.
\[ \frac{1}{-20} = \frac{1}{v_A} + \frac{1}{-25} \Rightarrow \frac{1}{v_A} = \frac{1}{25} - \frac{1}{20} = \frac{4-5}{100} = -\frac{1}{100} \Rightarrow v_A = -100 cm \]
Farther end (\( B \)): \( u_B = -(25 + 5) = -30 \) cm.
\[ \frac{1}{-20} = \frac{1}{v_B} + \frac{1}{-30} \Rightarrow \frac{1}{v_B} = \frac{1}{30} - \frac{1}{20} = \frac{2-3}{60} = -\frac{1}{60} \Rightarrow v_B = -60 cm \]
Length of image \( = |v_A - v_B| = |100 - 60| = 40 \) cm.



OR (YDSE Problem):

Let \( n_1 \)-th fringe of \( \lambda_1 \) coincide with \( n_2 \)-th fringe of \( \lambda_2 \). \[ n_1 \lambda_1 = n_2 \lambda_2 \Rightarrow \frac{n_1}{n_2} = \frac{600}{500} = \frac{6}{5} \]
Smallest integers are \( n_1 = 6, n_2 = 5 \). \[ y = \frac{n_1 \lambda_1 D}{d} = \frac{6 \times 500 \times 10^{-9} \times 1.8}{0.3 \times 10^{-3}} = \frac{3000 \times 10^{-9} \times 1.8}{3 \times 10^{-4}} = 1.8 \times 10^{-2} m = 18 mm \]


Step 4: Final Answer:

The length of the pencil's image is 40 cm. For the YDSE case, the least distance is 18 mm. Quick Tip: For objects placed along the axis (longitudinal), the image length is not simply magnification \(\times\) object length; you must calculate the image position for both ends separately.

Step 1: Understanding the Concept:

Isotopes have the same Atomic Number (\( Z \)). Isotones have the same Number of Neutrons (\( N = A - Z \)). Nuclear density is the ratio of nuclear mass to nuclear volume.


Step 2: Key Formula or Approach:

1. Nuclear Radius: \( R = R_0 A^{1/3} \)

2. Density \( \rho = \frac{Mass}{Volume} \)


Step 3: Detailed Explanation:

(a) Grouping:

- Isotopes: Same \( Z \). Here, \( ^{12}_{6}C \) and \( ^{14}_{6}C \) (both have \( Z=6 \)).

- Isotones: Same \( N \).
For \( ^{198}_{80}Hg \), \( N = 198 - 80 = 118 \).
For \( ^{197}_{79}Au \), \( N = 197 - 79 = 118 \).
So, \( ^{198}_{80}Hg \) and \( ^{197}_{79}Au \) are isotones.



(b) Density Proof:

The radius \( R = R_0 A^{1/3} \). \[ Volume V = \frac{4}{3} \pi R^3 = \frac{4}{3} \pi (R_0 A^{1/3})^3 = \frac{4}{3} \pi R_0^3 A \]
Mass of nucleus \( M \approx A \times m \), where \( m \) is average nucleon mass. \[ Density \rho = \frac{M}{V} = \frac{Am}{\frac{4}{3} \pi R_0^3 A} = \frac{3m}{4\pi R_0^3} \]
Since \( m \), \( \pi \), and \( R_0 \) are constants, \( \rho \) is independent of \( A \).


Step 4: Final Answer:

Isotopes: \( ^{12}_{6}C \), \( ^{14}_{6}C \). Isotones: \( ^{198}_{80}Hg \), \( ^{197}_{79}Au \). Density is constant because the volume increases proportionally with the mass number A. Quick Tip: Nuclear density is extremely high (approx \( 2.3 \times 10^{17} \) kg/m³), which is much denser than ordinary matter.

Step 1: Understanding the Concept:

Equipotential surfaces are always perpendicular to the electric field lines. For a uniform field along the x-axis, these are planes. Part (b) describes an electric dipole.




Step 2: Key Formula or Approach:

Potential \( V = \frac{k q}{r} \). Net potential is the algebraic sum: \( V_{net} = V_{+q} + V_{-q} \).


Step 3: Detailed Explanation:

(a) For \( \vec{E} = E_0 \hat{i} \), the electric field is uniform and directed along the positive x-axis. The equipotential surfaces are planes perpendicular to the x-axis (i.e., planes in the y-z orientation).



(b) Potential at \( P(x, 0, 0) \):
Distance from \( +q \) at \( (a, 0, 0) \): \( r_1 = x - a \).
Distance from \( -q \) at \( (-a, 0, 0) \): \( r_2 = x + a \). \[ V = \frac{1}{4\pi\varepsilon_0} \left[ \frac{q}{x-a} + \frac{-q}{x+a} \right] = \frac{q}{4\pi\varepsilon_0} \left[ \frac{(x+a) - (x-a)}{x^2 - a^2} \right] \] \[ V = \frac{q(2a)}{4\pi\varepsilon_0(x^2 - a^2)} = \frac{p}{4\pi\varepsilon_0(x^2 - a^2)} \]
Since \( x \gg a \), then \( x^2 - a^2 \approx x^2 \): \[ V \approx \frac{p}{4\pi\varepsilon_0 x^2} \]


Step 4: Final Answer:

(a) The surfaces are parallel planes perpendicular to the x-axis. (b) The potential is \( V = \frac{p}{4\pi\varepsilon_0 x^2} \). Quick Tip: The potential of a dipole decreases as \( 1/r^2 \), whereas the potential of a single point charge decreases more slowly as \( 1/r \).

Step 1: Understanding the Concept:

Electromagnetic waves are categorized by their frequency/wavelength in the EM spectrum. Each type has specific properties that make it suitable for different technological or medical applications.




Step 2: Detailed Explanation:


(i) Detection of bone fractures: X-rays. They can penetrate soft tissue but are absorbed by dense materials like bone.
(ii) Physiotherapy: Infrared waves (or sometimes Micro-waves for deep heat). Infrared lamps are used for treating muscular strains.
(iii) Radar systems: Microwaves. Their short wavelengths allow them to be reflected by small objects like aircraft.




Wavelength Ranges:
\begin{table[h]
\centering
\begin{tabular{|l|l|l|
\hline
Application & EM Wave & Approx. Wavelength Range
\hline
Fractures & X-rays & \(10^{-8}\) m to \(10^{-12}\) m
\hline
Physiotherapy & Infrared & \(10^{-3}\) m to \(7 \times 10^{-7}\) m
\hline
Radar & Microwaves & \(0.3\) m to \(10^{-3}\) m
\hline
\end{tabular
\end{table


Step 3: Final Answer:

(i) X-rays (\( 10^{-8} \) to \( 10^{-12} \) m), (ii) Infrared (\( 10^{-3} \) to \( 7 \times 10^{-7} \) m), (iii) Microwaves (\( 0.3 \) to \( 10^{-3} \) m). Quick Tip: Remember the order of the EM spectrum to easily recall ranges: Radio, Micro, Infrared, Visible, UV, X-ray, Gamma (increasing frequency/decreasing wavelength).

Step 1: Understanding the Concept:

Mutual inductance is the property where a change in current in one coil induces an electromotive force (EMF) in a nearby coil. For the solenoid-loop system, we use the magnetic field of the solenoid to find the flux through the loop. For parallel conductors, we apply the concept that a current-carrying wire in a magnetic field experiences a magnetic force.


Step 2: Key Formula or Approach:

1. Flux linked: \( \Phi = MI \).

2. Solenoid field: \( B = \mu_0 n I \).

3. Force on a wire: \( F = BIL \sin \theta \).


Step 3: Detailed Explanation:

(i) Mutual Inductance is defined as the magnetic flux linked with one coil per unit current flowing through the neighboring coil. Its SI unit is Henry (H).


(ii) The magnetic field inside a long solenoid carrying current \( I_1 \) is: \[ B_1 = \mu_0 n I_1 \]

The magnetic flux \( \Phi_2 \) linked with the inner circular loop of radius \( r \) is: \[ \Phi_2 = B_1 \times Area = (\mu_0 n I_1)(\pi r^2) \]
By definition, \( \Phi_2 = M I_1 \). Therefore: \[ M = \mu_0 n \pi r^2 \]


OR (Parallel Conductors):

Conductor A creates a magnetic field \( B_A \) at the location of conductor B: \[ B_A = \frac{\mu_0 I_A}{2\pi d} \]
The force \( F_{BA} \) on length \( L \) of conductor B is: \[ F_{BA} = I_B L B_A = I_B L \left( \frac{\mu_0 I_A}{2\pi d} \right) = \frac{\mu_0 I_A I_B L}{2\pi d} \]

By the Right-Hand Rule, this force is attractive (towards A). Similarly, the force on A due to B is: \[ F_{AB} = I_A L B_B = \frac{\mu_0 I_B I_A L}{2\pi d} \]
Since \( F_{AB} \) and \( F_{BA} \) are equal in magnitude and opposite in direction (\( \vec{F}_{AB} = -\vec{F}_{BA} \)), they obey Newton's Third Law.


Step 4: Final Answer:

The mutual inductance is \( M = \mu_0 n \pi r^2 \). The force between the parallel conductors is \( F = \frac{\mu_0 I_A I_B L}{2\pi d} \). Quick Tip: For mutual inductance, it doesn't matter which coil you start with (\( M_{12} = M_{21} \)); always choose the one where calculating the magnetic field is easier.

Step 1: Understanding the Concept:

Bohr’s model quantizes the orbits of electrons. The second postulate specifically quantizes the angular momentum, which restricts the electron to specific "stationary" orbits.


Step 2: Key Formula or Approach:

1. Angular momentum: \( L = mvr = \frac{nh}{2\pi} \).

2. Energy of \( n^{th} \) orbit: \( E_n = -\frac{13.6}{n^2} \) eV.


Step 3: Detailed Explanation:

(a) Postulate: An electron revolves around the nucleus only in those orbits for which the angular momentum is an integral multiple of \( h/2\pi \).

Significance: This postulate explains why electrons do not continuously lose energy and spiral into the nucleus, providing stability to the atom.


(b) The energy of an electron in the \( n^{th} \) level is \( E_n \propto -1/n^2 \). Let's look at the gap \( \Delta E \) between consecutive levels \( n \) and \( n+1 \): \[ \Delta E = E_{n+1} - E_n = -13.6 \left( \frac{1}{(n+1)^2} - \frac{1}{n^2} \right) = 13.6 \left( \frac{2n+1}{n^2(n+1)^2} \right) \]
For very large \( n \): \[ \Delta E \approx 13.6 \left( \frac{2n}{n^4} \right) \approx \frac{27.2}{n^3} \]
As \( n \) increases, \( \Delta E \) decreases significantly (it approaches zero). This proves the levels crowd together at higher energies.



Step 4: Final Answer:

Bohr’s second postulate quantizes angular momentum as \( L = n\hbar \). As \( n \to \infty \), the energy difference \( \Delta E \propto 1/n^3 \) vanishes, showing levels get closer. Quick Tip: The energy of the electron is negative because it is "bound" to the nucleus; \( E = 0 \) represents a free electron.

Step 1: Understanding the Concept:

A vector must satisfy the law of vector addition. Kirchhoff’s laws are based on the conservation of charge (Junction Rule) and energy (Loop Rule).


Step 2: Key Formula or Approach:

1. \( \sum I = 0 \) (Junction Rule).

2. \( \sum V = 0 \) (Loop Rule).


Step 3: Detailed Explanation:

(a) Arrows for current indicate the direction of flow of positive charge, but current is a scalar because it does not obey the laws of vector addition. For example, if two wires meet at a junction, the resulting current is the simple algebraic sum (\( I_1 + I_2 \)), regardless of the angle between the wires.


(b) Assuming a standard circuit (as the figure is not visible, we apply the general method):

1. Assign currents (\( I_1, I_2, I_3 \)) to each branch.
2. Apply the Junction Rule at a node: \( I_1 + I_2 = I_3 \).
3. Apply the Loop Rule (\( \sum V = 0 \)) to two independent loops.
4. Solve the resulting simultaneous equations to find the specific value for the \( 3\ \Omega \) resistor.


Step 4: Final Answer:

Current is a scalar due to algebraic addition. The numerical value of current depends on the specific battery voltages and resistances provided in the circuit diagram. Quick Tip: When traversing a loop, potential drops (\( -IR \)) if you go with the current and rises (\( +IR \)) if you go against it.

Step 1: Understanding the Concept:

We use the Biot-Savart Law for a small current element \( dl \) and integrate it. Due to the circular symmetry, the vertical components of the magnetic field cancel out, leaving only the axial components.


Step 2: Key Formula or Approach:

1. Biot-Savart Law: \( dB = \frac{\mu_0}{4\pi} \frac{I dl \sin \theta}{s^2} \).

2. Resultant field: \( B = \int dB \sin \phi \).


Step 3: Detailed Explanation:

Let \( P \) be a point on the axis at distance \( x \) from the center. Let \( s \) be the distance from element \( dl \) to \( P \), where \( s = \sqrt{r^2 + x^2} \).
The magnitude of \( dB \) is: \[ dB = \frac{\mu_0}{4\pi} \frac{I dl}{r^2 + x^2} \]

The axial component is \( dB \sin \phi \), where \( \sin \phi = r/s = \frac{r}{\sqrt{r^2+x^2}} \).
Integrating over the loop (\( \int dl = 2\pi r \)): \[ B = \int \frac{\mu_0 I r}{4\pi (r^2 + x^2)^{3/2}} dl = \frac{\mu_0 I r (2\pi r)}{4\pi (r^2 + x^2)^{3/2}} = \frac{\mu_0 I r^2}{2(r^2+x^2)^{3/2}} \]
For \( N \) turns: \[ B = \frac{\mu_0 N I r^2}{2(r^2+x^2)^{3/2}} \]


Step 4: Final Answer:

The magnetic field at distance \( x \) is \( B = \frac{\mu_0 N I r^2}{2(r^2+x^2)^{3/2}} \). Quick Tip: To find the field at the center, simply put \( x = 0 \), which gives the standard formula \( B = \frac{\mu_0 N I}{2r} \).

Step 1: Understanding the Concept:

A p-type semiconductor is created by adding trivalent impurities (atoms with 3 valence electrons) to a pure semiconductor like Silicon. This creates "holes" as majority charge carriers.


Step 2: Detailed Explanation:

Phosphorus, Arsenic, and Antimony are pentavalent (5 valence electrons) and create n-type semiconductors. Boron is trivalent, meaning it has one less electron than Silicon, creating a vacancy or a "hole."


Step 3: Final Answer:

The correct option is (C) Boron. Quick Tip: Remember the mnemonic: \textbf{BAlG} (Boron, Aluminium, Indium, Gallium) for p-type (trivalent) and \textbf{PAsSb} (Phosphorus, Arsenic, Antimony) for n-type (pentavalent).

Step 1: Understanding the Concept:

In a semiconductor under thermal equilibrium, the product of the concentrations of electrons (\( n_e \)) and holes (\( n_h \)) is constant and equal to the square of the intrinsic carrier concentration (\( n_i \)).


Step 2: Key Formula or Approach:

Mass Action Law: \[ n_e \cdot n_h = n_i^2 \]


Step 3: Detailed Explanation:

Given: \( n_e = 5 \times 10^{22} \) m\(^{-3}\) and \( n_i = 1.5 \times 10^{16} \) m\(^{-3}\). \[ n_h = \frac{n_i^2}{n_e} \] \[ n_h = \frac{(1.5 \times 10^{16})^2}{5 \times 10^{22}} \] \[ n_h = \frac{2.25 \times 10^{32}}{5 \times 10^{22}} \] \[ n_h = 0.45 \times 10^{10} = 4.5 \times 10^9 m^{-3} \]


Step 4: Final Answer:

The concentration of holes is (D) \( 4.5 \times 10^9 \) m\(^{-3}\). Quick Tip: The Mass Action Law applies to both intrinsic and extrinsic semiconductors as long as they are in thermal equilibrium.

Step 1: Understanding the Concept:

Forward bias occurs when the external voltage reduces the barrier potential, allowing majority carriers (holes from p-side and electrons from n-side) to cross the junction.




Step 2: Detailed Explanation:

In forward bias, the depletion region narrows. This allows majority carriers to diffuse across the junction. While the question uses the term "drifting," it refers to the movement of majority carriers which dominates the current flow. Minority carrier current (drift) is negligible in forward bias.


Step 3: Final Answer:

The correct option is (A). Quick Tip: In forward bias, current is in milliamperes (mA). In reverse bias, current is in microamperes (\( \mu \)A) or nanoamperes (nA).

Step 1: Understanding the Concept:

The threshold voltage (also called cut-in or knee voltage) is the minimum forward voltage required for the diode to start conducting significantly.




Step 2: Detailed Explanation:

Different semiconductor materials have different barrier potentials. For Germanium (Ge), it is approximately 0.2 V - 0.3 V. For Silicon (Si), it is approximately 0.7 V.


Step 3: Final Answer:

The correct option is (C) 0.7 V. Quick Tip: Silicon is preferred over Germanium in most applications because it has a higher temperature tolerance and lower leakage current, despite its higher threshold voltage.

Step 1: Understanding the Concept:

When an atom is doped into a crystal lattice, the "fifth" electron of a pentavalent impurity is very loosely bound. The energy required to move this electron into the conduction band is very small.


Step 2: Detailed Explanation:

For Germanium (Ge), the ionization energy for this donor electron is approximately 0.01 eV. For Silicon (Si), it is slightly higher, about 0.05 eV. This allows almost all donor atoms to be ionized at room temperature (\( \approx 0.025 \) eV).


Step 3: Final Answer:

The correct option is (A) 0.01 eV. Quick Tip: Because this energy is so small (less than the thermal energy at room temperature), n-type semiconductors have a high concentration of free electrons even without high external voltages.

Step 1: Understanding the Concept:

The Displacement Method is used to find the focal length of a convex lens. If the distance between the object and the screen (\( D \)) is greater than \( 4f \), there are two positions of the lens that produce a sharp image on the screen.




Step 2: Key Formula or Approach:

The focal length \( f \) in the displacement method is given by: \[ f = \frac{D^2 - d^2}{4D} \]
where \( d \) is the distance between the two positions of the lens.


Step 3: Detailed Explanation:

Rearranging the formula to solve for \( d \): \[ 4Df = D^2 - d^2 \] \[ d^2 = D^2 - 4Df \] \[ d^2 = D(D - 4f) \] \[ d = \sqrt{D(D - 4f)} \]


Step 4: Final Answer:

The correct option is (A). Quick Tip: For the displacement method to work, the distance \( D \) must be at least \( 4f \). If \( D = 4f \), the two positions of the lens coincide (\( d = 0 \)).

Step 1: Understanding the Concept:

In the displacement method, the two positions of the lens are conjugate. If in the first position the object distance is \( u \) and image distance is \( v \), then in the second position the object distance becomes \( v \) and image distance becomes \( u \).


Step 2: Detailed Explanation:

- In Position 1, the lens is closer to the object. Thus, \( u < v \). Magnification \( m_1 = v/u > 1 \), so the image is enlarged.

- In Position 2, the lens is moved closer to the screen. Thus, \( u > v \). Magnification \( m_2 = v/u < 1 \), so the image is reduced.


Step 3: Final Answer:

The correct option is (D) enlarged, reduced. Quick Tip: A useful property of these two images is that the size of the object (\( O \)) is the geometric mean of the sizes of the two images (\( I_1 \) and \( I_2 \)): \( O = \sqrt{I_1 I_2} \).

Step 1: Understanding the Concept:

We apply the displacement method formula using the provided values for the object-screen distance and the lens displacement.


Step 2: Key Formula or Approach:
\[ f = \frac{D^2 - d^2}{4D} \]


Step 3: Detailed Explanation:

Given: \( D = 80.00 \) cm, \( d = 20.00 \) cm. \[ f = \frac{80^2 - 20^2}{4 \times 80} \] \[ f = \frac{6400 - 400}{320} \] \[ f = \frac{6000}{320} = \frac{600}{32} \] \[ f = 18.75 cm \]


Step 4: Final Answer:

The focal length is (B) 18.75 cm. Quick Tip: Always ensure the units for \( D \) and \( d \) are the same before plugging them into the formula.

Step 1: Understanding the Concept:

For two distinct positions of the lens to exist in the displacement method, the condition \( D > 4f \) must be satisfied.


Step 2: Detailed Explanation:

Given: \( f = 15 \) cm.
The minimum distance required is: \[ 4f = 4 \times 15 = 60 cm \]
- If \( D < 60 \) cm: No real image can be formed on the screen.
- If \( D = 60 \) cm: Only one position exists.
- If \( D > 60 \) cm: Two distinct positions exist.

Evaluating the options:
(A) 45 cm (\( < 60 \))
(B) 50 cm (\( < 60 \))
(C) 55 cm (\( < 60 \))
(D) 65 cm (\( > 60 \))


Step 3: Final Answer:

The correct option is (D) 65 cm. Quick Tip: The distance \( 4f \) is the absolute minimum distance between a real object and its real image for a convex lens.

Step 1: Understanding the Concept:

When two thin lenses are in contact, their powers are additive. Power is the reciprocal of focal length (in meters).


Step 2: Key Formula or Approach:

1. \( P_{total} = P_1 + P_2 \)

2. \( P = \frac{100}{f(in cm)} \)


Step 3: Detailed Explanation:

Focal length of first lens \( f_1 = 10 \) cm. \[ P_1 = \frac{100}{10} = 10 D \]
Given total power \( P_{total} = 10/3 \) D. \[ \frac{10}{3} = 10 + P_2 \] \[ P_2 = \frac{10}{3} - 10 = \frac{10 - 30}{3} = -\frac{20}{3} D \]
Now, find \( f \): \[ f = \frac{100}{P_2} = \frac{100}{-20/3} = 100 \times \left(-\frac{3}{20}\right) \] \[ f = -15 cm \]


Step 4: Final Answer:

The focal length \( f \) is (A) –15 cm. (The negative sign indicates it is a concave lens). Quick Tip: Always be careful with the signs. Convex lenses have positive focal length/power, while concave lenses have negative focal length/power.

Step 1: Understanding the Concept:

Coherent sources are sources that emit light waves of the same frequency and maintain a constant phase difference. For the intensity calculation, we use the principle of superposition. For the telescope, we use ray optics to determine how angular magnification is achieved.


Step 2: Key Formula or Approach:

1. Phase difference \( \phi = \frac{2\pi}{\lambda} \times \Delta x \) (where \( \Delta x \) is path difference).

2. Resultant Intensity \( I = 4I_0 \cos^2\left(\frac{\phi}{2}\right) \).

3. Magnifying power of telescope (at infinity): \( m = \frac{f_o}{f_e} \).


Step 3: Detailed Explanation:

(a) Coherent Sources: Two sources are coherent if they emit waves of the same frequency and have a constant phase difference with time.

Necessity: If sources are not coherent, the phase difference at a point changes rapidly with time, causing the positions of maxima and minima to shift constantly. This results in a uniform average intensity, and no stable pattern is seen.




(b) Intensity Calculations:

(i) For \( \Delta x = \lambda/4 \): \( \phi = \frac{2\pi}{\lambda} \cdot \frac{\lambda}{4} = \frac{\pi}{2} \). \[ I = 4I_0 \cos^2\left(\frac{\pi/2}{2}\right) = 4I_0 \cos^2\left(\frac{\pi}{4}\right) = 4I_0 \left(\frac{1}{\sqrt{2}}\right)^2 = 2I_0 \]
(ii) For \( \Delta x = \lambda/3 \): \( \phi = \frac{2\pi}{\lambda} \cdot \frac{\lambda}{3} = \frac{2\pi}{3} \). \[ I = 4I_0 \cos^2\left(\frac{2\pi/3}{2}\right) = 4I_0 \cos^2\left(\frac{\pi}{3}\right) = 4I_0 \left(\frac{1}{2}\right)^2 = I_0 \]


OR (Telescope):

(a) Ray Diagram:

Magnifying Power: It is the ratio of the angle subtended by the image at the eye (\( \beta \)) to the angle subtended by the object at the lens (\( \alpha \)). \[ m = \frac{\beta}{\alpha} \approx \frac{\tan \beta}{\tan \alpha} \]
From the geometry of the lenses: \( \tan \alpha = \frac{h}{f_o} \) and \( \tan \beta = \frac{h}{f_e} \). \[ m = \frac{h/f_e}{h/f_o} = \frac{f_o}{f_e} \]

(b) (i) Aperture: The objective has a large aperture to collect more light from distant stars (increasing brightness) and to increase the resolving power of the telescope.

(ii) Advantages of Reflecting Telescope:
1. No chromatic aberration (as mirrors do not refract light).
2. Spherical aberration can be minimized using parabolic mirrors.


Step 4: Final Answer:

(a) Coherent sources have constant phase difference. (b) Intensities are \( 2I_0 \) and \( I_0 \). For the OR part, magnifying power is \( f_o/f_e \). Quick Tip: In a refracting telescope, the distance between the objective and eyepiece in normal adjustment is exactly \( L = f_o + f_e \).

Step 1: Understanding the Concept:

For the capacitor, capacitance is the ability to store charge, determined by geometry and the medium. For the conductor, we look at Drude's model of metallic conduction where electrons undergo frequent collisions, leading to a constant average velocity called drift velocity (\(v_d\)).




Step 2: Key Formula or Approach:

1. Gauss Law for Field: \(E = \sigma / \varepsilon_0\).

2. Capacitance: \(C = Q/V\).

3. Drift Velocity: \(v_d = \frac{eE\tau}{m}\).

4. Current relation: \(I = nAev_d\).


Step 3: Detailed Explanation:

(a) Capacitance Derivation:

Let the plates have charge density \(+\sigma\) and \(-\sigma\). The electric field between plates is: \[ E = \frac{\sigma}{\varepsilon_0} = \frac{Q}{A\varepsilon_0} \]
The potential difference \(V = E \times d\): \[ V = \frac{Qd}{A\varepsilon_0} \]
Since \(C = Q/V\): \[ C = \frac{Q}{Qd/A\varepsilon_0} = \frac{\varepsilon_0 A}{d} \]


(b) Dielectric Insertion (Battery Connected):

Since the battery remains connected, the potential \(V\) remains constant.
(i) Charge: New capacitance \(C' = KC\). Since \(Q = CV\), the new charge \(Q' = KCV = KQ\). Charge increases K times.

(ii) Energy: Energy \(U = \frac{1}{2}CV^2\). New energy \(U' = \frac{1}{2}(KC)V^2 = KU\). Energy increases K times.


OR (Conductor Part):

(a) Drift Velocity:

In the absence of an electric field, electrons move randomly (average velocity = 0). When \(E\) is applied, they accelerate (\(a = eE/m\)) but collide with ions. These collisions reset their velocity. The average time between collisions is \(\tau\). The steady average velocity attained is: \[ v_d = acceleration \times relaxation time = \frac{eE}{m} \tau \]

Current Relation: In time \(\Delta t\), electrons move distance \(v_d \Delta t\). Volume = \(A v_d \Delta t\). Number of electrons = \(n A v_d \Delta t\).
Total charge \(\Delta Q = (n A v_d \Delta t)e\). \[ I = \frac{\Delta Q}{\Delta t} = nAev_d \]


(b) (i) Instantaneous Current: Current is not established by one electron traveling from one end to the other. Instead, the electric field is established at the speed of light (\(c\)), causing electrons everywhere in the circuit to start drifting almost simultaneously.

(ii) Ratio of Drift Velocities: In series, current \(I\) is constant. \[ I = nA_1ev_{d1} = nA_2ev_{d2} \Rightarrow v_{d1}A_1 = v_{d2}A_2 \] \[ \frac{v_{d1}}{v_{d2}} = \frac{A_2}{A_1} = \frac{\pi r_2^2}{\pi r_1^2} = \left(\frac{r_2}{r_1}\right)^2 \]
Given \(r_1/r_2 = 3/2\), so \(r_2/r_1 = 2/3\): \[ \frac{v_{d1}}{v_{d2}} = \left(\frac{2}{3}\right)^2 = \frac{4}{9} \]


Step 4: Final Answer:

Capacitance is \(C = \varepsilon_0 A/d\). In parallel with battery connected, both charge and energy increase by factor \(K\). For the wires in series, the ratio of drift velocities is \(4:9\). Quick Tip: Always check if the battery is "connected" or "disconnected" when a dielectric is inserted. If connected, \(V\) is constant; if disconnected, \(Q\) is constant.

Step 1: Understanding the Concept:

A series LCR circuit involves resistors, inductors, and capacitors where the voltage across each is not in phase. An AC generator converts mechanical energy into electrical energy using the principle of electromagnetic induction.


Step 2: Key Formula or Approach:

1. Impedance: \( Z = \sqrt{R^2 + (X_L - X_C)^2} \).

2. Phase angle: \( \tan \phi = \frac{X_L - X_C}{R} \).

3. Induced EMF: \( \varepsilon = NBA\omega \sin(\omega t) \).


Step 3: Detailed Explanation:

(a) Impedance Derivation:

Let \( V_R, V_L, \) and \( V_C \) be the voltages across \( R, L, \) and \( C \). In a phasor diagram, \( V_R \) is in phase with current \( I \), \( V_L \) leads \( I \) by \( \pi/2 \), and \( V_C \) lags \( I \) by \( \pi/2 \).

The resultant voltage \( V \) is: \[ V = \sqrt{V_R^2 + (V_L - V_C)^2} = \sqrt{(IR)^2 + (IX_L - IX_C)^2} \] \[ V = I\sqrt{R^2 + (X_L - X_C)^2} \]
Since \( Z = V/I \): \[ Z = \sqrt{R^2 + (X_L - X_C)^2} \]
The phase difference \( \phi \) is given by: \[ \tan \phi = \frac{V_L - V_C}{V_R} = \frac{X_L - X_C}{R} \]


(b) (i) Minimum Impedance: This occurs at resonance, when \( X_L = X_C \). In this case, \( Z = R \).

(ii) Wattless Current: This flows when the power factor \( \cos \phi = 0 \). This happens in a purely inductive or purely capacitive circuit where the phase difference is \( \pi/2 \).


OR (AC Generator):

(i) Principle: It works on Faraday’s Law of Electromagnetic Induction. When a coil rotates in a magnetic field, the magnetic flux changes, inducing an EMF.

Construction: Consists of a Field Magnet, Armature (coil), Slip Rings, and Brushes.


Working: As the coil rotates, the angle \( \theta \) between the area vector and magnetic field changes, creating a varying flux.


(ii) EMF Expression:

Magnetic flux \( \Phi = NBA \cos \theta = NBA \cos(\omega t) \).
According to Faraday's Law: \[ \varepsilon = -\frac{d\Phi}{dt} = -NBA \frac{d}{dt}(\cos \omega t) = NBA\omega \sin(\omega t) \]
Let \( \varepsilon_0 = NBA\omega \), then \( \varepsilon = \varepsilon_0 \sin(\omega t) \).


(iii) Maximum EMF:

EMF is maximum when \( \sin(\omega t) = \pm 1 \).
This happens when \( \omega t = \pi/2, 3\pi/2 \).
Since \( \omega = 2\pi/T \):
1. \( \frac{2\pi}{T} t = \frac{\pi}{2} \Rightarrow t = \frac{T}{4} \)
2. \( \frac{2\pi}{T} t = \frac{3\pi}{2} \Rightarrow t = \frac{3T}{4} \)


Step 4: Final Answer:

Impedance is \( Z = \sqrt{R^2 + (X_L - X_C)^2} \). In an AC generator, EMF is \( \varepsilon = \varepsilon_0 \sin(\omega t) \), and it is maximum at times \( T/4 \) and \( 3T/4 \). Quick Tip: At resonance, the LCR circuit behaves like a purely resistive circuit, and the current is at its maximum possible value.
